PUMPA blue line PRO PSHD67.5 400V 50Hz, connection 6", drainage pump

Submersible cast iron drainage pump designed for pumping drainage water in the fields of civil engineering, such as mines, quarries, suitable for draining flooded rooms or pumping reservoirs, ponds, ponds, reservoirs, or rain collectors. The pump can be rented at our rental shop. See more

Technical Specifications

Automatic thermal protection
YES
Cable length [m]
8
Maximum immersion depth [m]
25
Maximum current [A]
15

Show all Tech Specs

on demand check availability

Goods cannot be purchased online. These are either oversized goods with an individual price of transport or an assortment that can only be purchased on demand. If you are interested in the goods, contact us at 800 100 763 or email [email protected]

2,264.87 € VAT included

Not sellable online

Register your business and get the benefits of a user account. %

Brand:
PUMPA
Category:
Wastewater pumps
Product No.:
ZB00055370
Sale group:
CEBLP
EAN:
8596455000983

Product variants

  • Technical Specifications
  • Product No.
  • Drinking water certificate
  • Automatic thermal protection
  • Cable length [m]
  • Maximum immersion depth [m]
  • Maximum current [A]
  • Power output - P2 [kW]
  • Capacitor
  • Construction
  • Maximum flow [l/min]
  • Maximum head [m]
  • Impeller material
  • Dry run protection
  • Float switch
  • Maximum particle size [mm]
  • Speed ​​control
  • Grinder
  • Protection [IP]
  • Off switch
  • Input voltage [V]
  • Delivery port ["]
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

PUMPA blue line PRO PSHD47.5 400V 50Hz, connection 4", drainage pump

Product No.: ZB00055369 Sale group: CEBLP EAN: 8596455000990

on demand
check availability
Product availability
  • central warehouse 0 pcs

2,076.93 €

Not sellable online

Automatic thermal protection
YES
Cable length [m]
8
Maximum immersion depth [m]
25
Maximum current [A]
15
Power output - P2 [kW]
7.50
Capacitor
NO
Construction
submersible
Maximum flow [l/min]
1,400
Maximum head [m]
41
Dry run protection
NO
Float switch
NO
Maximum particle size [mm]
11.50
Speed ​​control
NO
Grinder
NO
Protection [IP]
68
Input voltage [V]
3x400
Delivery port ["]
4

PUMPA blue line PRO PSHD67.5 400V 50Hz, connection 6", drainage pump

Product No.: ZB00055370 Sale group: CEBLP EAN: 8596455000983

on demand
check availability
Product availability
  • central warehouse 0 pcs

2,264.87 €

Not sellable online

Automatic thermal protection
YES
Cable length [m]
8
Maximum immersion depth [m]
25
Maximum current [A]
15
Power output - P2 [kW]
7.50
Capacitor
NO
Construction
submersible
Maximum flow [l/min]
2,080
Maximum head [m]
31
Dry run protection
NO
Float switch
NO
Maximum particle size [mm]
19.50
Speed ​​control
NO
Grinder
NO
Protection [IP]
68
Input voltage [V]
3x400
Delivery port ["]
6
You are viewing this variant

Product description

PUMPA Blue Line PRO PSHD Pump Application

  • water drainage in the fields of civil engineering, such as mines, quarries
  • suitable for drainage of flooded rooms
  • pumping of reservoirs, ponds, pools, cisterns or for rain collectors

PUMPA Blue Line PRO PSHD Pump Features

  • Motor and pump body made of solid cast iron for long life.
  • Significantly increased maximum immersion depth thanks to a high-pressure-resistant mechanical seal.
  • Semi-open impeller made of high quality chrome alloy.
  • Efficient engine cooling thanks to the drain channel cast as part of the engine cover.
  • Hermetically sealed built-in motor thermal protection.

Instructions

Technical Specifications

Automatic thermal protection
YES
Cable length [m]
8
Maximum immersion depth [m]
25
Maximum current [A]
15
Power output - P2 [kW]
7.50
Capacitor
NO
Construction
submersible
Maximum flow [l/min]
2,080
Maximum head [m]
31
Dry run protection
NO
Float switch
NO
Maximum particle size [mm]
19.50
Speed ​​control
NO
Grinder
NO
Protection [IP]
68
Input voltage [V]
3x400
Delivery port ["]
6
