Calpeda MXH 4801/A 230/400V 3kW

Horizontal Multi-Stage Close Coupled Pumps in stainless steel

See more

Technical Specifications

Pump design
horizontal
Drinking water certificate
YES
Automatic thermal protection
NO
Maximum current [A]
6.60

Show all Tech Specs

on demand check availability

1,283.35 € VAT included

On demand

Register your business and get the benefits of a user account. %

Brand:
CALPEDA
Category:
Horizontal surface pumps
Product No.:
ZB00025544
Sale group:
CECP
EAN:
8030485645580
Manuf. No.:
62245011000

Product variants

  • Technical Specifications
  • Product No.
  • Pump design
  • Drinking water certificate
  • Automatic thermal protection
  • Maximum current [A]
  • Power output - P2 [kW]
  • Capacitor
  • Construction
  • Maximum flow [l/min]
  • Maximum head [m]
  • Impeller material
  • Dry run protection
  • Speed ​​control
  • Suction port ["]
  • Maximum suction lift [m]
  • Protection [IP]
  • Off switch
  • Input voltage [V]
  • Delivery port ["]
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

Calpeda MXH 4801/A 230/400V 3kW

Product No.: ZB00025544 Sale group: CECP EAN: 8030485645580 Manuf. No.: 62245011000

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,283.35 €

Check availability

Pump design
horizontal
Drinking water certificate
YES
Automatic thermal protection
NO
Maximum current [A]
6.60
Power output - P2 [kW]
3
Capacitor
NO
Construction
multi-stage
Maximum flow [l/min]
1,100
Maximum head [m]
20
Impeller material
stainless steel
Dry run protection
NO
Speed ​​control
NO
Suction port ["]
3
Maximum suction lift [m]
8
Protection [IP]
54
Off switch
NO
Input voltage [V]
3x400
Delivery port ["]
2 1/2
You are viewing this variant

Calpeda MXH 4802/A 400V 5,5kW

Product No.: ZB00025545 Sale group: CECP EAN: 8030485592846 Manuf. No.: 62245021000

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,851.41 €

Not sellable online

Pump design
horizontal
Drinking water certificate
YES
Automatic thermal protection
NO
Maximum current [A]
10.80
Power output - P2 [kW]
5.50
Capacitor
NO
Construction
multi-stage
Maximum flow [l/min]
1,100
Maximum head [m]
41
Impeller material
stainless steel
Dry run protection
NO
Speed ​​control
NO
Suction port ["]
3
Maximum suction lift [m]
8
Protection [IP]
54
Off switch
NO
Input voltage [V]
3x400
Delivery port ["]
2 1/2

Calpeda MXH 4803/A 400V 7,5kW

Product No.: ZB00025546 Sale group: CECP EAN: 8030485580782 Manuf. No.: 62245031000

on demand
check availability
Product availability
  • central warehouse 0 pcs

2,517.83 €

Not sellable online

Pump design
horizontal
Drinking water certificate
YES
Automatic thermal protection
NO
Maximum current [A]
14.30
Power output - P2 [kW]
7.50
Capacitor
NO
Construction
multi-stage
Maximum flow [l/min]
1,100
Maximum head [m]
61
Impeller material
stainless steel
Dry run protection
NO
Speed ​​control
NO
Suction port ["]
3
Maximum suction lift [m]
8
Protection [IP]
54
Off switch
NO
Input voltage [V]
3x400
Delivery port ["]
2 1/2

Product description

Construction

Horizontal multi-stage close coupled pumps in chrome-nickel stainless steel.
Compact and robust construction, without protruding flange and with single-piece lantern bracket and base.
Single-piece barrel casing, with front suction port above pumps axis and radial delivery at top.
Filling and draining plugs on the middle of the pump, accessible from any side (like the terminal box).


Applications

- For water supply.
- For clean liquids, without abrasives, which are non-aggressive for stainless steel (with suitable seal materials, on request).
- Universal pump, for civil and industrial applications, for garden use and irrigation.
