PUMPA inox line STP-10 4-inch submersible pump 230V 2-wire with cable

Pump with motor and cable of the specified length, the 230V version is started directly in the motor. See more

Technical Specifications

Drinking water certificate
NO
Automatic thermal protection
YES
Cable length [m]
25 - 35
Maximum immersion depth [m]
200

Show all Tech Specs

in stock 3 pcs

from 519.18 € VAT included

Choose variant

Register your business and get the benefits of a user account. %

Brand:
PUMPA
Category:
Submersible borehole pumps
Product No.:
MAS001019

Product variants

  • Technical Specifications
  • Product No.
  • Drinking water certificate
  • Automatic thermal protection
  • Cable length [m]
  • Maximum immersion depth [m]
  • Maximum current [A]
  • Rated flow [l/m]
  • Power output - P2 [kW]
  • Rated head [m]
  • Capacitor
  • Construction
  • Maximum flow [l/min]
  • Maximum head [m]
  • Impeller material
  • Dry run protection
  • Float switch
  • Pump diameter ["]
  • Speed ​​control
  • Protection [IP]
  • Off switch
  • Maximum borehole diameter [mm]
  • Input voltage [V]
  • Delivery port ["]
  • Check valve
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

PUMPA inox line STP-1010 4" 0,55kW 230V 2-wire motor, submersible pump, cable 25m

Product No.: ZB00060215 Sale group: CEST EAN: 8596455017776

in stock
3 pcs
Product availability
  • central warehouse 3 pcs
  • available within 10 working days >10 pcs

519.18 €

Drinking water certificate
NO
Automatic thermal protection
YES
Cable length [m]
25
Maximum immersion depth [m]
200
Maximum current [A]
5
Rated flow [l/m]
35
Power output - P2 [kW]
0,55
Rated head [m]
49
Capacitor
integrated
Construction
centrifugal
Maximum flow [l/min]
50
Maximum head [m]
67
Impeller material
noryl
Dry run protection
NO
Float switch
NO
Pump diameter ["]
4
Speed ​​control
NO
Protection [IP]
68
Off switch
NO
Maximum borehole diameter [mm]
98
Input voltage [V]
230
Delivery port ["]
5/4

PUMPA inox line STP-1014 4" 0,75kW 230V 2-wire motor, submersible pump, cable 35m

Product No.: ZB00060219 Sale group: CEST EAN: 8596455017813

on demand
check availability
Product availability
  • central warehouse 0 pcs

577.02 €

Check availability

Drinking water certificate
NO
Automatic thermal protection
YES
Cable length [m]
35
Maximum immersion depth [m]
200
Maximum current [A]
6,20
Rated flow [l/m]
35
Power output - P2 [kW]
0,75
Rated head [m]
67
Capacitor
integrated
Construction
centrifugal
Maximum flow [l/min]
50
Maximum head [m]
92
Impeller material
noryl
Dry run protection
NO
Float switch
NO
Pump diameter ["]
4
Speed ​​control
NO
Protection [IP]
68
Off switch
NO
Maximum borehole diameter [mm]
98
Input voltage [V]
230
Delivery port ["]
5/4

Product description

Application

  • Drinking water supply for residential buildings from deep drilled wells
  • Utility and industrial water supply
  • Irrigation and other agricultural applications
  • Fire protection systems
  • Pressure amplification in high-rise buildings
  • Other applications

Characteristics

  • Stainless steel construction developed and manufactured to provide many years of fault-free operation
  • All metal parts are made of grade 304 stainless steel, except the shaft made of grade 431 stainless steel
  • Heavy-duty stainless steel discharge head with built-in check valve for long life and easy installation
  • Engine mounting specifications according to NEMA standard
  • High quality shaft bearings ensuring low friction and high wear resistance
  • Floating impellers are made with the addition of NorylR material for perfect sand processing.
  • Stainless steel strainer to prevent the ingress of sand and other impurities

Instructions

Technical Specifications

Drinking water certificate
NO
Automatic thermal protection
YES
Cable length [m]
25 - 35
Maximum immersion depth [m]
200
Maximum current [A]
5 - 6.20
Rated flow [l/m]
35
Power output - P2 [kW]
0.55 - 0.75
Rated head [m]
49 - 67
Capacitor
integrated
Construction
centrifugal
Maximum flow [l/min]
50
Maximum head [m]
67 - 92
Impeller material
noryl
Dry run protection
NO
Float switch
NO
Pump diameter ["]
4
Speed ​​control
NO
Protection [IP]
68
Off switch
NO
Maximum borehole diameter [mm]
98
Input voltage [V]
230
Delivery port ["]
5/4
