Technical Specifications

Automatic thermal protection
YES
Cable length [m]
10
Maximum immersion depth [m]
10
Maximum current [A]
3.30 - 5.20

Show all Tech Specs

on demand check availability

from 773.62 VAT included

Choose variant

Register your business and get the benefits of a user account. %

Brand:
HCP
Category:
Wastewater pumps
Product No.:
MAS000563

Product variants

  • Technical Specifications
  • Product No.
  • Drinking water certificate
  • Automatic thermal protection
  • Cable length [m]
  • Maximum immersion depth [m]
  • Maximum current [A]
  • Power output - P2 [kW]
  • Capacitor
  • Construction
  • Maximum flow [l/min]
  • Maximum head [m]
  • Impeller material
  • Dry run protection
  • Float switch
  • Maximum particle size [mm]
  • Speed ​​control
  • Grinder
  • Protection [IP]
  • Off switch
  • Input voltage [V]
  • Delivery port ["]
  • Availability
  • Price
    • ZB00003007
    • YES
    • 10
    • 10
    • 3,30
    • 0,40
    • integrated
    • submersible
    • 320
    • 9,50
    • stainless steel
    • NO
    • NO
    • 35
    • NO
    • NO
    • 68
    • 230
    • on demand
      check availability
      Product availability
      • central warehouse 0 pcs
    • 773.62
    • Check availability
    • ZB00003008
    • YES
    • 10
    • 10
    • 3.30
    • 0.40
    • integrated
    • submersible
    • 320
    • 9.50
    • stainless steel
    • NO
    • YES
    • 35
    • NO
    • NO
    • 68
    • 230
    • on demand
      check availability
      Product availability
      • central warehouse 0 pcs
    • 798.31
    • Check availability
    • ZB00003010
    • YES
    • 10
    • 10
    • 5,20
    • 0,75
    • integrated
    • submersible
    • 400
    • 12,50
    • stainless steel
    • NO
    • NO
    • 35
    • NO
    • NO
    • 68
    • 230
    • on demand
      check availability
      Product availability
      • central warehouse 0 pcs
    • 847.68
    • Check availability
    • ZB00003011
    • YES
    • 10
    • 10
    • 5.20
    • 0.75
    • integrated
    • submersible
    • 400
    • 12.50
    • stainless steel
    • NO
    • YES
    • 35
    • NO
    • NO
    • 68
    • 230
    • on demand
      check availability
      Product availability
      • central warehouse 0 pcs
    • 872.36
    • Check availability

next

Variant Product No.

Availability

Price (VAT incl.)

Product No.: ZB00003007 Sale group: CEHC1 Manuf. No.: 1025000510

773.62 €

Automatic thermal protection
YES
Cable length [m]
10
Maximum immersion depth [m]
10
Maximum current [A]
3,30
Power output - P2 [kW]
0,40
Capacitor
integrated
Construction
submersible
Maximum flow [l/min]
320
Maximum head [m]
9,50
Impeller material
stainless steel
Dry run protection
NO
Float switch
NO
Maximum particle size [mm]
35
Speed ​​control
NO
Grinder
NO
Protection [IP]
68
Input voltage [V]
230

Product No.: ZB00003008 Sale group: CEHC1 Manuf. No.: 1025000520

798.31 €

Automatic thermal protection
YES
Cable length [m]
10
Maximum immersion depth [m]
10
Maximum current [A]
3.30
Power output - P2 [kW]
0.40
Capacitor
integrated
Construction
submersible
Maximum flow [l/min]
320
Maximum head [m]
9.50
Impeller material
stainless steel
Dry run protection
NO
Float switch
YES
Maximum particle size [mm]
35
Speed ​​control
NO
Grinder
NO
Protection [IP]
68
Input voltage [V]
230

Product No.: ZB00003010 Sale group: CEHC1 Manuf. No.: 1025002110

847.68 €

Automatic thermal protection
YES
Cable length [m]
10
Maximum immersion depth [m]
10
Maximum current [A]
5,20
Power output - P2 [kW]
0,75
Capacitor
integrated
Construction
submersible
Maximum flow [l/min]
400
Maximum head [m]
12,50
Impeller material
stainless steel
Dry run protection
NO
Float switch
NO
Maximum particle size [mm]
35
Speed ​​control
NO
Grinder
NO
Protection [IP]
68
Input voltage [V]
230

Product No.: ZB00003011 Sale group: CEHC1 Manuf. No.: 1025002120

872.36 €

Automatic thermal protection
YES
Cable length [m]
10
Maximum immersion depth [m]
10
Maximum current [A]
5.20
Power output - P2 [kW]
0.75
Capacitor
integrated
Construction
submersible
Maximum flow [l/min]
400
Maximum head [m]
12.50
Impeller material
stainless steel
Dry run protection
NO
Float switch
YES
Maximum particle size [mm]
35
Speed ​​control
NO
Grinder
NO
Protection [IP]
68
Input voltage [V]
230

Technical Specifications

Automatic thermal protection
YES
Cable length [m]
10
Maximum immersion depth [m]
10
Maximum current [A]
3.30 - 5.20
Power output - P2 [kW]
0.40 - 0.75
Capacitor
integrated
Construction
submersible
Maximum flow [l/min]
320 - 400
Maximum head [m]
9.50 - 12.50
Impeller material
stainless steel
Dry run protection
NO
Float switch
NO, YES
Maximum particle size [mm]
35
Speed ​​control
NO
Grinder
NO
Protection [IP]
68
Input voltage [V]
230
