Calpeda MXS 9xx multi-stage submersible clean water pumps in stainless steel

  • Calpeda MXS 9xx multi-stage submersible clean water pumps in stainless steel
    Calpeda MXS 9xx multi-stage submersible clean water pumps in stainless steel
  • Calpeda MXS 9xx multi-stage submersible clean water pumps in stainless steel
    Calpeda MXS 9xx multi-stage submersible clean water pumps in stainless steel
  • Calpeda MXS 9xx multi-stage submersible clean water pumps in stainless steel
    Calpeda MXS 9xx multi-stage submersible clean water pumps in stainless steel

Drinking water certificate Stainless steel

previous next
Calpeda MXS 9xx multi-stage submersible clean water pumps in stainless steel Calpeda MXS 9xx multi-stage submersible clean water pumps in stainless steel Calpeda MXS 9xx multi-stage submersible clean water pumps in stainless steel
Calpeda MXS 9xx multi-stage submersible clean water pumps in stainless steel

Multi-Stage Submersible Clean Water Pumps in stainless steel FLOW 1 / 11 mc/h HEAD 12 / 105 m POWER 0.55 / 3 kW

See more

Technical Specifications

Drinking water certificate
YES
Automatic thermal protection
NO
Cable length [m]
15
Maximum immersion depth [m]
20

Show all Tech Specs

on demand check availability

from 662.26 € VAT included

Choose variant

Register your business and get the benefits of a user account. %

Brand:
CALPEDA
Category:
Submersible pumps
Product No.:
MAS001271

Product variants

  • Technical Specifications
  • Product No.
  • Drinking water certificate
  • Automatic thermal protection
  • Cable length [m]
  • Maximum immersion depth [m]
  • Maximum current [A]
  • Rated flow [l/m]
  • Power output - P2 [kW]
  • Rated head [m]
  • Capacitor
  • Construction
  • Maximum flow [l/min]
  • Maximum head [m]
  • Impeller material
  • Dry run protection
  • Float switch
  • Pump diameter ["]
  • Speed ​​control
  • Protection [IP]
  • Off switch
  • Maximum borehole diameter [mm]
  • Input voltage [V]
  • Delivery port ["]
  • Check valve
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

Calpeda MXS 903 1,1kW 400V 15m cable

Product No.: ZB00025571 Sale group: CECK EAN: 8030485725381 Manuf. No.: 72F15031000

on demand
check availability
Product availability
  • central warehouse 0 pcs

662.26 €

Check availability

Drinking water certificate
YES
Automatic thermal protection
NO
Cable length [m]
15
Maximum immersion depth [m]
20
Maximum current [A]
2.60
Rated flow [l/m]
150
Power output - P2 [kW]
1.10
Rated head [m]
21.50
Capacitor
NO
Construction
centrifugal
Maximum flow [l/min]
183.30
Maximum head [m]
34.50
Impeller material
stainless steel
Dry run protection
NO
Float switch
NO
Pump diameter ["]
5
Speed ​​control
NO
Protection [IP]
X8
Off switch
NO
Maximum borehole diameter [mm]
133
Input voltage [V]
3x400
Delivery port ["]
5/4

Calpeda MXS 904 1,5kW 400V 15m cable

Product No.: ZB00025572 Sale group: CECK EAN: 8030485707325 Manuf. No.: 72F05042000

on demand
check availability
Product availability
  • central warehouse 0 pcs

739.31 €

Check availability

Drinking water certificate
YES
Automatic thermal protection
NO
Cable length [m]
15
Maximum immersion depth [m]
20
Maximum current [A]
3.80
Rated flow [l/m]
150
Power output - P2 [kW]
1.50
Rated head [m]
30
Capacitor
NO
Construction
centrifugal
Maximum flow [l/min]
183.30
Maximum head [m]
45.50
Impeller material
stainless steel
Dry run protection
NO
Float switch
NO
Pump diameter ["]
5
Speed ​​control
NO
Protection [IP]
X8
Off switch
NO
Maximum borehole diameter [mm]
133
Input voltage [V]
3x400
Delivery port ["]
5/4

Calpeda MXS 905 2,2kW 400V cable 15m

Product No.: ZB00025573 Sale group: CECK EAN: 8030485662556 Manuf. No.: 72F05052000

on demand
check availability
Product availability
  • central warehouse 0 pcs

896.01 €

Check availability

Drinking water certificate
YES
Automatic thermal protection
NO
Cable length [m]
15
Maximum immersion depth [m]
20
Maximum current [A]
4.30
Rated flow [l/m]
150
Power output - P2 [kW]
2.20
Rated head [m]
38.50
Capacitor
NO
Construction
centrifugal
Maximum flow [l/min]
183.30
Maximum head [m]
58
Impeller material
stainless steel
Dry run protection
NO
Float switch
NO
Pump diameter ["]
5
Speed ​​control
NO
Protection [IP]
X8
Off switch
NO
Maximum borehole diameter [mm]
133
Input voltage [V]
3x400
Delivery port ["]
5/4

Calpeda MXS 906 2,2kW 400V 15m cable

Product No.: ZB00025574 Sale group: CECK EAN: 8030485703501 Manuf. No.: 72F05062000

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,028.54 €

Check availability

Drinking water certificate
YES
Automatic thermal protection
NO
Cable length [m]
15
Maximum immersion depth [m]
20
Maximum current [A]
5.60
Rated flow [l/m]
150
Power output - P2 [kW]
2.20
Rated head [m]
46.50
Capacitor
NO
Construction
centrifugal
Maximum flow [l/min]
183.30
Maximum head [m]
70
Impeller material
stainless steel
Dry run protection
NO
Float switch
NO
Pump diameter ["]
5
Speed ​​control
NO
Protection [IP]
X8
Off switch
NO
Maximum borehole diameter [mm]
133
Input voltage [V]
3x400
Delivery port ["]
5/4

Calpeda MXS 907 3kW 400V 15m cable

Product No.: ZB00025575 Sale group: CECK EAN: 8030485712619 Manuf. No.: 72F05072000

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,164.94 €

Check availability

Drinking water certificate
YES
Automatic thermal protection
NO
Cable length [m]
15
Maximum immersion depth [m]
20
Maximum current [A]
6.60
Rated flow [l/m]
150
Power output - P2 [kW]
3
Rated head [m]
58
Capacitor
NO
Construction
centrifugal
Maximum flow [l/min]
183.30
Maximum head [m]
81
Impeller material
stainless steel
Dry run protection
NO
Float switch
NO
Pump diameter ["]
5
Speed ​​control
NO
Protection [IP]
X8
Off switch
NO
Maximum borehole diameter [mm]
133
Input voltage [V]
3x400
Delivery port ["]
5/4

Calpeda MXS 908 3kW 400V 15m cable

Product No.: ZB00025576 Sale group: CECK EAN: 8030485716457 Manuf. No.: 72F05082000

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,351.11 €

Check availability

Drinking water certificate
YES
Automatic thermal protection
NO
Cable length [m]
15
Maximum immersion depth [m]
20
Maximum current [A]
8.50
Rated flow [l/m]
150
Power output - P2 [kW]
3
Rated head [m]
66
Capacitor
NO
Construction
centrifugal
Maximum flow [l/min]
183.30
Maximum head [m]
93
Impeller material
stainless steel
Dry run protection
NO
Float switch
NO
Pump diameter ["]
5
Speed ​​control
NO
Protection [IP]
X8
Off switch
NO
Maximum borehole diameter [mm]
133
Input voltage [V]
3x400
Delivery port ["]
5/4

Calpeda MXS 909 3kW 400V 15m cable

Product No.: ZB00001395 Sale group: CECK EAN: 8030485725398 Manuf. No.: 72F05092000

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,573.71 €

Check availability

Drinking water certificate
YES
Automatic thermal protection
NO
Cable length [m]
15
Maximum immersion depth [m]
20
Maximum current [A]
8.50
Rated flow [l/m]
150
Power output - P2 [kW]
3
Rated head [m]
73.50
Capacitor
NO
Construction
centrifugal
Maximum flow [l/min]
183.30
Maximum head [m]
105
Impeller material
stainless steel
Dry run protection
NO
Float switch
NO
Pump diameter ["]
5
Speed ​​control
NO
Protection [IP]
X8
Off switch
NO
Maximum borehole diameter [mm]
133
Input voltage [V]
3x400
Delivery port ["]
5/4

Calpeda MXS 910 3kW 400V 15m cable

Product No.: ZB00025577 Sale group: CECK EAN: 8030485768890 Manuf. No.: 72F05102000

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,681.20 €

Check availability

Drinking water certificate
YES
Automatic thermal protection
NO
Cable length [m]
15
Maximum immersion depth [m]
20
Maximum current [A]
8.50
Rated flow [l/m]
150
Power output - P2 [kW]
3
Rated head [m]
81.50
Capacitor
NO
Construction
centrifugal
Maximum flow [l/min]
183.30
Maximum head [m]
117
Impeller material
stainless steel
Dry run protection
NO
Float switch
NO
Pump diameter ["]
5
Speed ​​control
NO
Protection [IP]
X8
Off switch
NO
Maximum borehole diameter [mm]
133
Input voltage [V]
3x400
Delivery port ["]
5/4

Product description

Construction

Close coupled multi-stage submersible pumps.
All parts in contact with the fluid both internal and external are in chrome-nickle stainless steel.
MXSM with built-in capacitor, accessible through the delivery casing.
Hydraulics located below the motor with the motor cooled by the pumped fluid. Safe operation is possible with the motor only partially submerged.
Double shaft seal with oil chamber.
The suction strainer prevents the entrance of solids with diameter bigger than 2 mm.

Applications

- For water supply from wells, tanks or reservoirs.
- For domestic, civil and industrial applications, for garden use, irrigation and rain water harvesting systems.

Instructions

Technical Specifications

Drinking water certificate
YES
Automatic thermal protection
NO
Cable length [m]
15
Maximum immersion depth [m]
20
Maximum current [A]
2.60 - 8.50
Rated flow [l/m]
150
Power output - P2 [kW]
1.10 - 3
Rated head [m]
21.50 - 81.50
Capacitor
NO
Construction
centrifugal
Maximum flow [l/min]
183.30
Maximum head [m]
34.50 - 117
Impeller material
stainless steel
Dry run protection
NO
Float switch
NO
Pump diameter ["]
5
Speed ​​control
NO
Protection [IP]
X8
Off switch
NO
Maximum borehole diameter [mm]
133
Input voltage [V]
3x400
Delivery port ["]
5/4
